Wall Hung Toilet Partition System
Our Wall Hung Toilet Partition System delivers a clean, streamlined appearance by mounting all panels directly onto the wall with no floor or ceiling supports. Built with reinforced brackets and high-quality materials, the system is ideal for projects that require a simple, practical, and low-maintenance solution.
Built for Wet & Humid Environments
Engineered to withstand heavy daily use in Singapore’s wet, humid, and high-traffic conditions without warping, swelling, or delamination.
Clean-Friendly Surfaces
Highly Vandal-Resistant and waterproof surfaces allow quick and effortless cleaning, while the dense HPL/PVC structure offers exceptional resistance against scratches, graffiti, and impact.
Colour & Surface Stability
Fade-resistant materials that maintain their colour, finish, and structural stability over years of use even in demanding commercial environments.
Manufactured using high-quality HPL Phenolic Compact Laminate or PVC boards, our wall mounted toilet cubicles deliver exceptional durability and reliable performance. Ideal for offices, shopping malls, hotels, educational institutions, hospitals, and public facilities, BestCube's Wall Hung Toilet Cubicle Systems offer a premium washroom solution that combines functionality, hygiene, and contemporary design.
Wall Mounted Cubicle System
Wall Hung Toilet Partition System is a practical choice for A&A works, toilet upgrading and renovation projects where the existing side walls are already solid cement or tiled walls.
Many clients choose this system when they do not want to hack down the existing cement or tiled partition walls, but only want to replace or upgrade the cubicle doors, fittings and finishing. The system provides a cleaner look while keeping the existing wall structure in place.
This makes it a suitable option for washrooms that require a cost-effective upgrade with less demolition work, faster installation and easier maintenance.
Wall Hung Toilet Cubicle Systems Feature & Specifications
Cubicle Doors
- Material: 12mm compact laminate
- Hinges: Heavy-duty gravity self-closing hinges
- Edges: Chamfered edges, no metal trimmings
- Recommended Door Widths: Standard door – 600mm Ambulant door – 820mm
- Overall Door Height: 1980mm (measured from FFL to top of door, inclusive of 150mm floor gap)
Cubicle Pilasters
- Material: 12mm compact laminate
- Support: heavy-duty extruded aluminium top rail for added rigidity and support
- Recommended Pilaster Widths: Centre pilaster – 300mm End pilaster – 150mm
- Overall Pilaster Height: 2125mm (FFL to top of overhead rail, inclusive of 150mm floor gap)
Dividing Partitions
- Material: 12mm compact laminate
- Installation: Secured to both end wall and pilaster using extruded aluminium U-channel fittings
- Maximum Recommended Width: 1830mm
- Overall Partition Height: 1980mm (FFL to top of divider, inclusive of 150mm floor gap)
Hardware Accessories – Stainless Steel
Each cubicle comes with:
- Stainless steel thumbturn lockset (with emergency coin release)
- Heavy-duty self-closing stainless steel hinges (adjustable for fully closed, partially open or fully open positions)
- Stainless steel coat hook with rubber stopper
- Stainless steel 42mm door knob
Aluminium Fittings
- Aluminium H top rail secured to both end walls
- Heavy-duty extruded aluminium U-channel for end panels
- Powder-coated U-channel and H top rail
